Logic Functions - Book 2
SEQUENCE BLOCK
10-19
21 Failure Error Unacked (FAILU) ....................................................................................... – WR
If the failure error diagnostic is enabled, the unacknowledged status indicates if the diagnostic
is or is not acknowledged. Only writeable in DEBUG.
NO 0 Diagnostic error is acknowledged.
YES 1 Diagnostic error is unacknowledged.
22 Failure Error Unacked Quality (FAILUQ) ....................................................................... – WR
If the failure error diagnostic is enabled, this status indicates if the quality of the
unacknowledged diagnostic is GOOD or BAD. Only writeable in DEBUG.
GOOD 0 Quality when the block STATE is RUN or HOLD.
BAD 1 Quality when the block STATE is OFF.
23 Failure Error Active (FAILA) ............................................................................................ – WR
If the failure error diagnostic is enabled, the active status indicates if the diagnostic is active
even after acknowledgement. Only writeable in DEBUG.
NO 0 Diagnostic error is not active.
YES 1 Diagnostic error is active.
24 Failure Error Active Quality(FAILAQ) ............................................................................. – WR
If the failure error diagnostic is enabled, this status indicates if the quality of the active
diagnostic is GOOD or BAD. Only writeable in DEBUG.
GOOD 0 Quality when the block STATE is RUN or HOLD.
BAD 1 Quality when the block STATE is OFF.
25 Step on Cold Start (CSSTEP) ...........................................................................................CWR
The step on which the sequence starts after a power interruption that exceeds the Cold Start
Duration configured in the Interface Block
PREVIOUS The step prior to the current operating step
Count Number of any configured step
NOTE: When a configuration is downloaded, the configuration software initially sets
the sequence to start on Step 1. The Step on Cold Start attribute must
not be configured as previous for download because this results in the
sequence being set to Step 0 which prevents the block from starting.
26 Step on Warm Start (WSSTEP).........................................................................................CWR
The step on which the sequence starts after a power interruption that exceeds the Warm Start
Duration configured in the Interface Block
PREVIOUS The step prior to the current operating step
Count Number of any configured step
