Luminex 100 IS Version 2.2 - Manual (Page 52)

Luminex 100 IS Developer Guide to x MAP Technology Version 2.2 x MAP Technology
46 PN 89-00002-00-032 Rev. A
Figure 29. Template Setup Wizard Dialog Box
2. Fill in the general information about your company, the author of
the template, the name and version for the template you are
creating, and a brief description. The required version number of
the template is very important because it is automatically
included in the template name that the lab personnel sees when
they select the template to use with a kit.
3. Select Qualitative for the Template Type.
4. Enter the Sample Vol (uL) for this template. This is the amount
of sample for testing. Make the volume in the wells at least 25
uL greater than the sample volume.
5. Enter a Sample Timeout (sec) for this template to set the
maximum time that the analyzer will spend acquiring data for
each sample.
6. Enter the Low Limit and High Limit for the Doublet
Discriminator Gate.
Select
Qualitative
