Luminex 100 IS Version 2.2 - Manual (Page 39)

x MAP Technology Create Products
PN 89-00002-00-032 Rev. A 33
6. Enter the Test Name (analyte) and Test Units used for each test.
Note: If the test name is similar and the units are the same for
each test, after entering the first test name and unit, click the
Apply Suffix or Apply Unit buttons as appropriate.
Apply Suffix—this button applies the number one to the first
test name. For each successive test name it applies the test name
and number at one increment higher than the previous test name.
For example: Suffix = Protein, then Test 1 is Protein 1, Test 2 is
Protein 2, and so on.
Apply Unit—this button applies the same unit value entered on
the first line to all other tests. For example, if mg/uL is entered
for the first Test Unit, then select Apply Unit to make all tests
mg/uL.
7. Enter the Number of Standards for this product and press
Enter key.
8. Enter the Reagent Name for each standard in this product. Each
standard reagent must test for every analyte (bead set) used in the
assay. See example in Figure 22.
Note: If the reagent names are similar, click the Apply Suffix
button to ensure each name is unique.
9. After entering all the information, check it carefully. When all
the information is correct, click Save to save the product.
10. Click Close.
Assay Controls
‹ To create a product that consists of only assay controls:
1. Click the Create New Product button on the toolbar. The Create
New Product dialog box appears listing the existing products.
See Figure 21.
2. Click New to enter a new product into the system. You do not
need to press the New button for the first use.
