Delay-2
English Manual 75
Delay-2
The Delay-2 algorithm occupies:
– @ Normal Sample Rate: 1/4 DSP Resource
– @ Double Sample Rate: 1/4 DSP Resource
The inputs and outputs of this algorithm are dis-
tributed as follows:
Input Output
L
E1
E2
E3
E4
L
R R
Delay-2 algorithm – introduction
This M5000 algorithm is a 24 bit true stereo ef-
fect offering Delays of up to 2.5 sec in each
channel with two filtered feedback controls per
channel (self feedback and x feedback). Delays
may be modulated with control over relative L/R
phase for Chorus or Tape Delay emulation. The
System 6000 implementation of Delay 2 can be
used with sample rates of up to 96 kHz.
Delay-2 algorithm – main page
Delay Line 1
Delay 1
Range: 1 to 2500 ms
Sets the Delay time for the left side.
Level 1
Range: Off to 0.0 dB
The Output level of channel 1.
Pan 1
Range: 50 L – Center – 50 R
Controls the position of channel 1 in the stereo
image.
Delay Line 2
Delay 2
Range: 1 to 2500 ms
Sets the Delay time for the right side.
Level 2
Range: Off to 0.0 dB
The Output level of channel 2.
Pan 2
Range: 50 L – Center – 50 R
Controls the position of channel 2 in the stereo
image.
Delay EQ
Hi Cut Freq
Range: 500 Hz to flat
Hi Cut filter, shelving type. Provides an over-
all high frequency roll-off (6 dB per octave) that
is well suited to make the Delay effect sound
warmer.
Hi Cut Att
Range: -40 to 0.0 dB
The attenuation control sets the amount of high
frequency roll-off determined by the Hi Cut pa-
rameter in 0.5 dB steps.
Levels
Mix
Range: 0 to 100 %
Sets the mix between dry and wet signal.
In Level
Range: -100 to 0 dB
Adjusts the Input level of the algorithm.
Out Level
Range: -100 to 0 dB
Adjusts the Output level of the algorithm.
Pan Invert
Range: Off / On
Inverts the panning settings for the two Delay
Lines.
