VSS™ 6.1 Reverb
46 System 6000 MKII Algorithms
Surr. Hi Cut
Range: 20 Hz to 20 kHz
Hi Cut parameter for the Reverb Diffuse fields in
the Surround channels.
Note that this parameter can be linked to Front Hi
Cut on the Decay page.
Master Early
Each Location Type (see Setup page) has a pre-
defined colorization. The Hi and Lo Color alter
the default color of the selected Location.
Lo Color
Range: -50 to 50
Master Lo Color adjustment of the Early Reflec-
tions.
Hi Color
Range: -50 to 50
Master Hi Color adjustment of the Early Reflec-
tions.
ER. Decrease – Restrictions in Order
Range: 0 to 100 %
Reflection patterns in System 6000 are rendered
to a high order, but you may not always be inter-
ested in having a full emulation, e.g. if the micro-
phone already has picked up some reflections.
Based upon perceptual experiments, we have
found that reducing particular reflections is a
method most useful for optimizing the room re-
sponse to a given microphone placement. The
0 % setting enables the full response, which
should be preferred for very closely mic’ed
sources, while 100 % ER Decrease is useful for
sources picked up at a distance.
Note: 1 st order reflections have hit one surface
before arriving at the listener, 2 nd order reflec-
tions two surfaces etc. High order reflections are
often more diffuse than low order ones. In Sys-
tem 6000 this effect is emulated by assigning in-
dividual diffusion characteristics to each reflec-
tion. More information about how to make the
most of these vital possibilities is available in the
paragraph “Early Reflections working for You”.
Levels
Reverb Level
Range: Off to 0 dB
Master output Level control of the Diffuse Field
response.
Early Level
Range: Off to 0 dB
Master output Level control of the Early Reflec-
tions.
Front LR Level
Range: Off to 0 dB
Master wet level control (Early Reflections + Dif-
fuse Field) of the Left and Right front channels.
Center Level
Range: Off to 0 dB
Master wet level control (Early Reflections + Dif-
fuse Field) of the Center channel.
Surround Level
Range: Off to 0 dB
Master wet level control (Early Reflections + Dif-
fuse Field) of the Left and Right surround chan-
nels.
Center Surround Level
Range: Off to 0 dB
Master wet level control (Early Reflections + Dif-
fuse Field) of the Center surround channel.
VSS™ 6.1 Reverb algorithm
– setup page
VSS™ 6.1 Reverb algorithm – setup page
