Unwrap HD
142 System 6000 MKII Algorithms
Range for the Notch filter:
– Lo BW: 0.02 to 1 oct
– Mid1 BW: 0.02 to 1 oct
– Mid2 BW: 0.02 to 1 oct
– Hi BW: 0.02 to 1 oct
Range for the Parametric filter:
– Lo BW: 0.1 to 4 oct
– Mid1 BW: 0.1 to 4 oct
– Mid2 BW: 0.1 to 4 oct
– Hi BW: 0.1 to 4 oct
Range for the Shelve filter:
– Lo BW: 3 to 12 dB/oct
– Hi BW: 3 to 12 dB/oct
Range for the Cut filter:
– Lo BW: Bessel or Butterworth
– Hi BW: Bessel or Butterworth
Unwrap HD algorithm – delay page
Unwrap HD algorithm – delay page
Output Delay
Range: 0 to 200 ms
For each of the six outputs it’s possible to adjust
the Delay time in Milliseconds.
Fine Adjust Output Delay
Range: 0 to 100 samples
In addition to the Output Delay in milliseconds,
it’s possible to adjust each of the six Output De-
lays in samples resolution.
The total Delay on an Output channel is the nor-
mal ms Delay setting, PLUS the Sample Delay
setting.
The actual time a Delay set in Samples varies de-
pending on running Sample Rate. E.g. if you are
running 48 kHz, a 48 samples delay equals 1 ms,
and at 96 kHz it equals 0.5 ms.
Unwrap HD algorithm
– output page
Unwrap HD algorithm – output page
Outputs
Mute
Range: Muted/Unmuted
Sets the Mute-status on the Output for each of
the 6 channels.
Solo
When a Solo button is selected, the Outputs of
all the five remaining channels will be set to Off,
but they can be selected as additional solo chan-
nels.
Output Levels
Range: -120 to +12 dB
Individual Output levels for the six Output chan-
nels.
Fader
Range: -120 to 0 dB
Fades all six Outputs simultaneously.
Preserves the individual Output levels until either
the maximum or minimum value is reached.
