VSS™ 5.1 Source
English Manual 43
Will not be available when Output Mode is set
to Stereo.
Mid Color
Range: ±50
Additional Color adjustment of the Surround
channels. Adjusts the spectral balance in the
mid-end frequencies of the Reverb.
Will not be available when Output Mode is set
to Stereo.
Hi Color
Range: ±50
Additional Color adjustment of the Surround
channels. Adjusts the spectral balance in the hi-
end frequencies of the Reverb.
Will not be available when Output Mode is set
to Stereo.
Reverb Decays
The following 5 parameters are multipliers for
each of the five channels according to the Mas-
ter Decay parameter.
Decay and Multipliers to general explanation
The Decay time is generally defined as the time
it takes for the Reverb diffused field to decay
60 dB. In this algorithm the overall Decay time is
set using the Master Decay parameter.
To control the individual Decay time of the five
channels we use multipliers. By using different
multiplier settings for each of the 5 channels the
Decay time for each channel can be controlled.
Example:
If the Master Decay parameter is set to 2.0 sec
and e.g. the LFr parameter is set to 1.5, the ac-
tual Decay time for the LFr channel will be 3.0
sec. (1.5 x 2.0) Conversely if this parameter is set
to 0.5 the Decay time for that channel will be 1
sec. (0.5 x 2.0).
LFr Decay
Range: 0.10 to 2.00
Adjusts the left-front speaker Reverb Decay time.
Center Decay
Range: 0.10 to 2.00
Adjusts the Center speaker Reverb Decay time.
RFr Decay
Range: 0.10 to 2.00
Adjusts the right-front speaker Reverb Decay
time.
LSr Decay
Range: 0.10 to 2.00
Adjusts the left-surround speaker Reverb Decay
time.
Master Decay
Range: 0.10 to 20.00
The Master Decay parameter simultaneously ad-
justs the Decay time for all five diffused Fields
relatively to the multiplier-settings for each chan-
nel.
RSr Decay
Range: 0.10 to 2.00
Adjusts the right-surround speaker Reverb De-
cay time.
VSS™ 5.1 Source algorithm
– modulation page
VSS™ 5.1 Source algorithm – modulation page
Modulation is available and operates on the Re-
verb part of the algorithm.
