Core-2
English Manual 11
Core-2
The TC Electronic REV CORE algorithms are
particularly good for small room simulations.
Due to the high density structure the relatively
short Reverb diffuse fields occurring in small
rooms can be convincingly reproduced. Though
the VSS™ algorithms are dedicated for Film and
Post production the Rev Core algorithm, known
from the TC M5000 are also highly usable for
purposes as such. You will also find that it is a
good choice on percussive material, as it is very
smooth an non-coloring.
The Reverb Core-2 algorithm occupies:
– @ Normal Sample Rate: 1/4 DSP Resource
– @ Double Sample Rate: 1/4 DSP Resource
The inputs and outputs of this algorithm are dis-
tributed as follows:
Input Output
L
E1
E2
E3
E4
L
R R
Rev Core-2 algorithm – main page
Rev Core-2 algorithm – main page
Main
Decay
Range: 0.3 to 60 s
Reverberation Decay time.
Pre Delay
Range: 0 to 200 ms
Sets the time that passes before the first reflec-
tion appear. (see table 1 on the next page). In-
creasing the predelay will change the apparent
position and, to some degree, the size of the
room.
Reverb Delay
Range: 0 to 100 ms
Delay time on the Reverb Tail only. Where the
Pre Delay parameter sets the Delay time on the
entire algorithm, Early Reflections as well as Re-
verb Tail, the Reverb Delay parameter works on
the Reverb Tail only.
Hi Cut Freq
Range: 500 Hz to flat
Hi Cut filter, shelving type. Provides an over-
all Reverb high frequency roll-off (6 dB per oc-
tave) that is suitable for making the space sound
warmer.
Hi Cut Att
Range: -40.0 to 0.0 dB
With the Hi-Cut Att. parameter you can attenuate
the frequency area specified by the Hi-Cut Freq
parameter.
Levels
Early Level
Range: Off to 0 dB
Sets the level for the Early Reflections.
Reverb Level
Range: Off to 0.0 dB
Sets the level of the reflection envelope relative
to the Early Reflections in 0.5 dB steps. If Reverb
Level is set to off you will hear only the Early Re-
flections.
