FSRxxxx SERIES

Z205739-0D

PAGE 49

©2013 Veris Industries USA 800.354.8556 or +1.503.598.4564 / [email protected]

05131

Alta Labs, Enercept, Enspector, Hawkeye, Trustat, Aerospond, Veris, and the Veris ‘V’ logo are trademarks or registered trademarks of Veris Industries, L.L.C. in the USA and/or other countries.

TM

INSTALLATION GUIDE

TO

:

RATE PULSE, TOT

AL PULSE,

4-20mA,

TOTAL

RESET

OR RS485 I/O IF USED

95 - 264 VAC

AC NEUTRAL

USER EQUIPMENT

DISCONNECT

( NOTE 2,3 )

OFF

ON

ANACONDA SEALTITE

TYPE UA-1/2 FLEXIBLE CONDUIT

OR EQUIVALENT

*

CROUSE-HINDS

CONDUIT CONNECTOR

OR EQUIVALENT

*

BY OTHERS

BY

O

TH

ER

S

*

Substitute part must be suitable for Class I, II, Div 2, Groups C, D.

1.

Information shown on this drawing is provided to indicate wiring requirements to comply with National Electrical Code

®

(NEC) Article 500.

2.

Disconnect to be located near the Flow meter. Do not position the

AC

POWERED

HAZARDOUS

AREA

INSTALLATION

NAME:

FLOW METER

WIRE USED TO BE 14 GA, 60ºC, 600V

( NOTE 4 )

Fig

ur

e A

-6

.3 - H

az

ar

do

us A

rea I

ns

ta

lla

tio

n
