background image

FSRxxxx SERIES

Z205739-0D

PAGE 35

©2013 Veris Industries USA 800.354.8556 or +1.503.598.4564 / [email protected]

05131

Alta Labs, Enercept, Enspector, Hawkeye, Trustat, Aerospond, Veris, and the Veris ‘V’ logo are trademarks or registered trademarks of Veris Industries, L.L.C. in the USA and/or other countries.

TM

INSTALLATION GUIDE

APPENDIX

Specifications

Monitor

Power Requirements

AC: 95-264 VAC 47-63 Hz at 17 VA Maximum.
DC: 10-28 VDC at 5.0 W.
Protection: Reverse polarity and transient suppression.
AC: Field replaceable fuse.
DC: Auto resettable fuse.

Installation Compliance

General Safety: UL 61010-1, CSA C22.2 No. 61010-1 and EN 61010-1
Hazardous Location: Class I Division 2 Groups C,D; Class II and III, Division 2, Groups C, D, F, and G for US/CAN; Class I, Zone 2, AEx nA IIB T6; ATEX II 2 G EEx nA II T6: UL

1604, CSA 22.2 No. 213, EN 60079-0 and EN 60079-15

CE: EN61326-1:2006 on integral flow transducers or remote transducers with conduit

Display

2 line LCD, LED backlight.
Top Row: 7 segment, 0.7” (18 mm) high, numeric.
Bottom Row: 14 segment, 0.35” (9 mm) high alpha-numeric.
Flow Rate Indication: 8 digit positive, 7 digit negative max.; auto decimal, lead zero blanking.
Flow Totalizer: 8 digit positive, 7 digit negative. Reset via software, keypad, contact closure.

Engineering Units

User configured.

Rate

Gal, liters, million gal, ft³, m³, acre-ft, oil barrels (42 gal), liquid barrels (31.5 gal), ft, m, lb, kg.
Additional units for Energy version BTU, MBTU, MMBTU, Ton, kJ, kW, MW

Time

Seconds, minutes, hours, days.

Totalizer

Gal, liters, million gal, ft³, m³, acre-ft, oil barrels (42 gal), liquid barrels (31.5 gal), lb, kg.
Additional units for Energy version BTU, MBTU, MMBTU, Ton, kJ, kW, MW

Mode

Forward, reverse, net, batch.

Input/Output
(all transmitters)

All modules optically isolated from earth and system ground.

4-20 mA

12-bit resolution, internal power (current source). Can span negative to positive flow/energy rates.

USB

2.0 for connection of a PC. (Requires USB interface cable).

10/100 Base-T

RJ45 communications via Modbus TCP/IP, Ethernet/IP™ and BACnet®/IP.

RS-485

Modbus RTU command set.

System

Liquid Types

Most clean liquids or liquids containing small amounts of suspended solids or gas bubbles.

Velocity Range

Bidirectional to greater than 40 FPS (12 MPS).

Flow Accuracy

FST1, FST2, FST3:
1” (25 mm) and larger units 1% of reading from 10 to 100% of measurement range; within 0.01 FPS (0.003 MPS) at lower rates.
Smaller than 1” (25 mm) units are 1% of full scale.
FST4, FST5:
1% of reading at rates from 4-40 FPS (1.2-12 MPS); +/- 0.04 FPS (0.012 MPS) at rates < 4 FPS (1.2 MPS).

Flow Repeatability

±0.01% of reading.

Flow Sensitivity

0.001 FPS (0.0003 MPS).

Temperature Accuracy
(Energy Meters Only)

32 to 212 °F (0 to 100 °C);
Absolute 0.45 °F (0.25 °C), Difference 0.18 °F (0.1 °C).

Temperature Sensitivity

0.05 °F (0.025 °C).

Temperature Repeatability

±0.5% of reading.
