FSRxxxx SERIES

Z205739-0D

PAGE 41

©2013 Veris Industries USA 800.354.8556 or +1.503.598.4564 / [email protected]

05131

Alta Labs, Enercept, Enspector, Hawkeye, Trustat, Aerospond, Veris, and the Veris ‘V’ logo are trademarks or registered trademarks of Veris Industries, L.L.C. in the USA and/or other countries.

TM

INSTALLATION GUIDE

Modbus Coil

Description

Modbus

Coil

Notes

Reset Totalizers

1

Forcing this coil on will reset all totalizers. After

reset, the coil automatically returns to the

off state.

Table A-3.4 - Modbus Coil Map

Object Description

BACnet

Object

(Access

Point)

Notes

Available Units

Signal Strength

AI1

Analog Input 1

Flow Rate (Flow model)
Energy Rate (BTU model)

AI2

Analog Input 2

Gallons, Liters,

MGallons, Cubic Feet,

Cubic Meters, Acre

Feet, Oil Barrel, Liquid

Barrel, Feet, Meters,

Lb, Kg, BTU, MBTU,

MMBTU, TON, kJ, kW,

MW

Per Second, Minute,

Hour, Day

Net Totalizer

AI3

Analog Input 3

Positive Totalizer

AI4

Analog Input 4

Negative Totalizer

AI5

Analog Input 5

Temperature 1

AI6

Analog Input 6

ºC

Temperature 2

AI7

Analog Input 7

ºC

Reset Totalizers

BO1

Binary Output 1

Writing an (1)

active state to this

object will reset

all totalizers. The

Object will then

automatically

return to the (0)

inactive state.

Table A-3.5 - BACnet® Object Mappings

Network Settings:

IP address, IP subnet, IP gateway, and Device Description are configured through the
web interface. IP address and subnet defaults to 192.168.0.100 and 255.255.255.0.
Connection to the web interface requires an Ethernet crossover cable, power to the
flow meter, and a PC with a web browser. Type http://192.168.0.100 in the address
bar to allow connection to the flow meter’s web interface for editing.

Web Interface
user name: admin [enter]
password: [none, enter]

Note: Changing the IP address requires use of the new number when trying to access the web
page. Each meter must be setup with a unique IP address when trying to network multiple units.

When making changes to the IP address, retain the new number for future access.

Edit

Edit

Edit

Diagnostics

TFX

Device Configuration

BACnet Device ID: 100

Location

Enter location information here

Network Settings

192.168.0.100
255.255.255.0
0.0.0.0

IP Address:

Subnet Mask:

Gateway IP Address:

Network Status

00:40:9D:00:00:00
1.08
FULL
100 MBPS

MAC Address:

Software Revision:

Link Duplex:

Link Speed:

Diagnostics Web Page

The Diagnostics web page refreshes itself every 5 seconds and provides real time data
from the meter.

Diagnostics

Main Page

Device Values

Signal Strength

22.8

Flow Rate

100.4

Net Totalizer

1659.1

Positive Totalizer

1659.1

Negative Totalizer

0.0

Temp 1

26.5

Temp 2

48.7

This page will automatically refresh every 5 seconds

Reset Totalizers

Main Page
