INSTALLATION GUIDE
9. Press “Download” on the “System Configuration” screen to save the calibration
values to the flow meter. After the download is complete, power cycle the meter
to make the newly downloaded values take effect.
If the calibration points are not separated by at least 40°C or if either one or both of
the RTDs are open, the following error message appears.
Calibration points are too close. Calibration not usable.
USP
OK
!
Check the RTDs resistance values with an ohmmeter to make sure they are not
shorted. See Table A-4.2 for typical RTD resistance values. Next check to ensure that
incorrect “Cal Point” values were not entered inadvertently.
Heat Capacity of Water (J/g°C)
°C
0
1
2
3
4
5
6
7
8
9
0
4.2174 4.2138 4.2104 4.2074 4.2045 4.2019 4.1996 4.1974 4.1954 4.1936
10 4.1919 4.1904 4.1890 4.1877 4.1866 4.1855 4.1846 4.1837 4.1829 4.1822
20 4.1816 4.0310 4.1805 4.1801 4.1797 4.1793 4.1790 4.1787 4.1785 4.1783
30 4.1782 4.1781 4.1780 4.1780 4.1779 4.1779 4.1780 4.1780 4.1781 4.1782
40 4.1783 4.1784 4.1786 4.1788 4.1789 4.1792 4.1794 4.1796 4.1799 4.1801
50 4.1804 4.0307 4.1811 4.1814 4.1817 4.1821 4.1825 4.1829 4.1833 4.1837
60 4.1841 4.1846 4.1850 4.1855 4.1860 4.1865 4.1871 4.1876 4.1882 4.1887
70 4.1893 4.1899 4.1905 4.1912 4.1918 4.1925 4.1932 4.1939 4.1946 4.1954
80 4.1961 4.1969 4.1977 4.1985 4.1994 4.2002 4.2011 4.2020 4.2029 4.2039
90 4.2048 4.2058 4.2068 4.2078 4.2089 4.2100 4.2111 4.2122 4.2133 4.2145
Table A-4.1 - Heat Capacity of Water
STANDARD RTD (Ohms)
°C
°F
100 Ω
1000 Ω
-50
-58
80.306
803.06
-40
-40
84.271
842.71
-30
-22
88.222
882.22
-20
-4
92.160
921.60
-10
14
96.086
960.86
0
32
100.000
1000.00
10
50
103.903
1039.03
20
68
107.794
1077.94
25
77
109.735
1097.35
30
86
111.673
1116.73
40
104
115.541
1155.41
50
122
119.397
1193.97
60
140
123.242
1232.42
70
158
127.075
1270.75
80
176
130.897
1308.97
90
194
134.707
1347.07
100
212
138.506
1385.06
110
230
142.293
1422.93
120
248
146.068
1460.68
130
266
149.832
1498.32
Table A-4.2 - Standard RTD Resistance Values
