INSTALLATION GUIDE
Menu Maps
Acrylic
Aluminum
Brass (Naval)
Carbon Steel
Cast Iron
Copper
Ductile Iron
Fiberglass-Epoxy
Glass Pyrex
Nylon
HD Polyethylene
LD Polyethylene
Polypropylene
PVC CPVC
PVDF
St Steel 302/303
St Steel 304/316
St Steel 410
St Steel 430
PFR
Titanium
Other
PIPE MAT
Pipe Material
English (FPS)
Metric (MPS)
PIPE SS
Pipe Sound Speed
Numeric Entry
PIPE R
Relative Roughness
English (Inches)
Metric (mm)
LINER T
Pipe Liner Thickness
English
Metric
UNITS
Programming Units
V
W
Z
XDCR MNT
Transducer Mounting
English (Inches)
Metric (mm)
PIPE OD
Pipe Outside Diameter
English (Inches)
Metric (mm)
PIPE WT
Pipe Wall Thickness
500 KHz
1 MHz
2 MHz
XDUCR HZ
Transducer Frequency
English (FPS)
Metric (MPS)
LINER SS
Pipe Liner Sound Speed
Water Tap
Sewage
Acetone
Alcohol
Ammonia
Benzene
Ethanol
Ethylene Glycol
Gasoline
Glycerin
Isopropyl Alcohol
Kerosene
Methanol
Oil Diesel
Oil Hydraulic (petro-base)
Oil Lubricating
Oil Motor (SAE 20/30)
Water Distilled
Water Sea
Other
FL TYPE
Fluid Type
Tar Epoxy
Rubber
Mortar
Polypropylene
Polystyrene
HDPE
LDPE
Teflon (PFA)
Ebonite
Other
LINER TYPE
Pipe Liner Material
English (FPS)
Metric (MPS)
FLUID SS
Fluid Sound Speed
CPS
FLUID VI
Fluid Viscosity
Numeric Entry
SP GRVTY
Specific Gravity
Numeric Entry
SP HEAT
Nominal Heat Capacity
English (Inches)
Metric (mm)
Note: This value is calculated
by firmware.
XDC SPAC
Transducer Spacing
Gallons
Liters
MGal
Cubic Ft
Cubic Me
Acre Ft
Oil Barr (42 Gal)
Liq Barr (31.5 Gal)
Feet
Meters
LB
KG
1 BTU
1 MBTU
1 MMBTU
1 Ton
1 kJ
1 kWh
1 MWh
RATE UNT
Rate Units
Sec
Min
Hour
Day
RATE INT
Rate Interval
Gallons
Liters
MGal
Cubic Ft
Cubic Me
Acre Ft
Oil Barr (42 Gal)
Liq Barr (31.5 Gal)
Feet
Meters
LB
KG
1 BTU
1 MBTU
1 MMBTU
1 Ton
1 kJ
1 kWh
1 MWh
TOTL UNT
Total Units
E-1 (-10)
E0 (X1)
E1 (X10)
E2 (X100)
E3 (X1,000)
E4 (X10,000)
E5 (X100,000)
E6 (X1,000,000)
TOTL E
Totalizer Exponent
Numeric Entry
MIN RATE
Minimum Flow Rate
Numeric Entry
MAX RATE
Maximum Flow Rate
Numeric Entry
FL C-OFF
Low Flow Cutoff
Numeric Entry
DAMP PER
Damping Percentage
Numeric Entry (1-126)
ADDRESS
Multi-Drop Device Address
Numeric Entry
LINER R
Liner Roughness
Forward
Reverse
FLOW DIR
Flow Direction
BASIC MENU
Page 2 Page 3
1 These heat flow
measurements only
appear when RTD is
chosen in the Output 2
menu.
Page 1
