ENGINE INDICATION SYSTEM
3.2 ENGINE PAGE
NOTE: The Fuel Quantity Indicator will display only to 50 gallons per side when full.
The EIS Engine Page displays engine, fuel, fuel calculation, electrical, and cabin temperature information using
round dial gauges, bar indicators, bar graphs, and digital readouts.
Accessing the EIS - Engine Page:
1) Press the ENGINE Softkey.
2) To return to the previously viewed page, press the ENGINE Softkey or turn the large FMS Knob.
1 Engine Manifold Pressure
Gauge (MAN IN HG)
Displays manifold pressure in inches of Mercury (in Hg) to indicate engine power
Turbocharged Aircraft – Maximum manifold pressure range displayed in red
2 Tachometer
(RPM)
Displays propeller speed in revolutions per minute (rpm); the red range
indicates propeller overspeed
3 Engine Temperature Group
(EGT °F, CHT °F, TIT °F)
For each cylinder the head temperatures are displayed in degrees Fahrenheit
(°F)
Normally-aspirated Aircraft – Exhaust gas temperatures (EGT) are displayed
for each cylinder in °F
Turbocharged Aircraft – Turbine inlet temperature is displayed in °F
4 Electrical Group
(ESS BUS, EMER BATT,
MAIN ALT, STBY ALT,
BATT)
Voltages for the essential bus and emergency battery, along with currents (in
amperes, A) for the main and standby alternators and battery are displayed
using vertical bar indicators and readouts
5 Fuel Calculations Group
(GAL REM, GAL USED,
ENDUR, RANGE NM)
The totalizer-based fuel remaining and fuel used and the totalizer-based
endurance and range calculations are displayed
6 Cabin Temperature Gauge
(CABIN °F)
Displays cabin temperature in °F
7 Fuel Quantity Gauges
(L/R FUEL QTY GAL)
Gauges display the amount of fuel in gallons (gal)
8 Oil Temperature/Pressure
Gauge
(OIL °F PSI)
Oil temperature in °F is displayed on the left half of the gauge and pressure
is displayed on the right in pounds per square inch (psi)
9 Fuel Flow Gauge
(FFLOW GPH)
Displays fuel flow in gallons per hour (gph)
