GPS NAVIGATION
190-00692-00 Rev. B 5-124 Garmin G1000 Pilot’s Guide for Piper PA32
5.19 FLIGHT PLANNING (PFD)
Flight planning on the PFD centers around the Flight Plan Window (Figure 5-135) where flight plans can be
created, edited, and activated. The Flight Plan Window is enabled and disabled by pressing the FPL Key.
Desired Track
Next Available
Memory Position
Figure 5-135 Flight Plan Window
Flight Plan Title
Leg Distance
Active Leg
OPERATIONS
The following operations can be performed using the Flight Plan Window Menu (Figure 5-136).
• Activate leg
• Store, invert, or delete flight plan
• Load or remove departure, arrival, or approach
• Closest Point of FPL
• Restore defaults
• Parallel track
Figure 5-136 Flight Plan Page Menu
CREATE NEW FLIGHT PLAN
Up to 99 flight plans with up to 99 waypoints in each flight plan can be created and stored in memory.
