190-00692-00 Rev. B Garmin G1000 Pilot’s Guide for Piper PA32 1-10
SYSTEM OVERVIEW
NOTE: When a key is selected, a triangular annunciator above the key is illuminated.
1 COM1 MIC – Selects the #1 transmitter for transmitting. COM1 receiver is simultaneously selected when
this key is pressed, allowing received audio from the #1 Com receiver to be heard. COM2 receiver audio
can be added by pressing the COM2 Key.
2 COM1 – When selected, audio from the #1 Com receiver can be heard.
3 COM2 MIC – Selects the #2 transmitter for transmitting. COM2 receiver is simultaneously selected when
this key is pressed, allowing received audio from the #2 Com receiver to be heard. COM2 can be deselected
by pressing the COM2 Key, or COM1 can be added by pressing the COM1 Key.
4 COM2 – When selected, audio from the #2 Com receiver can be heard.
5 COM3 MIC – Not used.
6 COM3 – Not used.
7 COM 1/2 – Split COM is disabled.
8 TEL – Not used.
9 PA – Selects the passenger address system. The selected Com transmitter is deselected when the PA Key
is pressed.
10 SPKR – Pressing this key selects and deselects the corresponding cockpit speaker. Com and Nav receiver
audio will be heard on the speaker.
11 MKR/MUTE – Mutes the currently received Marker Beacon Receiver audio. Unmutes when new marker
beacon audio is received. Also stops play of the Clearance Recorder.
12 HI SENS – Press to increase Marker Beacon Receiver sensitivity. Press again to return to normal.
13 DME – Pressing turns DME audio on or off.
14 NAV1 – When selected, audio from the #1 Nav receiver can be heard.
15 ADF – Pressing turns on or off the audio from the ADF receiver.
16 NAV2 – When selected, audio from the #2 Nav receiver can be heard.
17 AUX – Not used.
18 MAN SQ – Press to enable manual squelch for the intercom. When active, press the PILOT Knob to
illuminate ‘SQ’. Turn the PILOT/PASS Knobs to adjust squelch.
19 PLAY – Press once to play the last recorded audio. Press again to begin playing the previously recorded memory
block. Each subsequent press of the PLAY Key will begin playing the next recorded block . Press the MKR/MUTE
Key to stop play.
20 PILOT – Pressing selects the pilot intercom isolation. Press again to deselect pilot isolation.
