190-00692-00 Rev. B Garmin G1000 Pilot’s Guide for Piper PA32 8-45
ADDITIONAL FEATURES
NOTE: A subdued softkey label indicates the function is disabled.
FliteCharts time critical information can also be found on the AUX - System Status Page. The FliteCharts
database ‘REGION’, ‘CYCLE’ number, ‘EFFECTIVE’, ‘EXPIRES’, and ‘DISABLES’ dates of the subscription appear
in either blue or yellow text. Dates shown in blue are current data. Dates shown in yellow indicate the data is
not within the current subscription period.
FliteCharts becomes inoperative 180 days after the FliteCharts ‘EXPIRES’ date is reached, and is no longer
available for viewing. This date is shown as the ‘DISABLES’ date. After the disable date the SHW CHRT Softkey
label appears subdued and is unavailable until a revised issue of FliteCharts is installed.
Press the DBASE Softkey for scrolling through the database information. Scroll through the database with
the FMS knob or ENT Key.
The FliteCharts database cycle number shown in Figure 8-55, ‘0604’ is broken down as follows:
06 – Indicates the year 2006
04 – Indicates the fourth issue of the FliteCharts database for the year
The FliteCharts ‘EFFECTIVE’ date “13–APR–06” is the first date that this database is current.
The FliteCharts ‘EXPIRES’ date “11–MAY–06” is the last date that this database is current.
The ‘DISABLES’ date “07–NOV–06” is the date that this database becomes inoperative.
DBASE Softkey
Selected
FliteCharts
Data
Figure 8-55 AUX – System Status Page, FliteCharts Current and Available
The FliteCharts database is provided from Garmin. Refer to Updating Garmin Databases in Appendix B for
instructions on revising the FliteCharts database.
