GPS NAVIGATION
190-00692-00 Rev. B 5-40 Garmin G1000 Pilot’s Guide for Piper PA32
5.5 DIRECT-TO-NAVIGATION (PFD)
Figure 5-38 PFD Direct-to Window
Waypoint Symbol
Facility Name
Identifier City, State
VNV Altitude
Constraint
Along Track
Offset
Distance to Waypoint
Course to Selected Waypoint
Bearing From Waypoint
A direct-to waypoint can be selected in the following ways:
• By identifier, waypoint location or facility name
• From a list of waypoints in the active flight plan
• From a list of 25 nearest airports
The PFD Direct-to window is enabled and disabled by pressing the Direct-to Key ( ) . The currently
selected waypoint displays the information shown in Figure 5-38.
Direct-to Navigation from the PFD:
1) Press the Direct-to Key ( ) .
2) Turn the large FMS Knob to place the cursor in the desired selection field.
3) Turn the small FMS Knob to begin selecting the desired identifier, location, etc.
4) Press the ENT Key.
5) The cursor is now flashing on ‘ACTIVATE?’. If no altitude constraint or course is desired, press the ENT Key to
activate. To enter an altitude constraint, proceed to step 6.
6) Turn the large FMS Knob to place the cursor over the ‘VNV’ altitude field.
Figure 5-39 Entering Altitude Constraint
Altitude Constraint
