Garmin G1000 Pilot’s Guide for Piper PA32
190-00692-00 Rev. B
6-24
HAZARD AVOIDANCE
CYCLONE
Cyclone data shows the current location of cyclones (hurricanes) and their projected track. The forecasted
track can be displayed at various time intervals.
Displaying Cyclone (hurricane) track information:
1)
Select the Weather Data Link Page.
2)
Press the MORE WX Softkey.
3)
Press the CYCLONE Softkey.
Cyclone data displays only on the Weather Data Link Page. It does not display on other G1000 maps.
To display the Cyclone legend (Figure 6-31), press the LEGEND Softkey when Cyclones are selected to be
displayed.
Figure 6-31 Cyclone Legend
SETTING UP THE WEATHER DATA LINK PAGE
The display of weather data on the Weather Data Link Page can be set up and customized by using the Data
Link Menu (Figure 6-32). Weather legends for all active products can also be accessed from the Data Link
Menu.
Figure 6-32 Data Link Menu
