190-00692-00 Rev. B

Garmin G1000 Pilot’s Guide for Piper PA32

1-12

SYSTEM OVERVIEW

1.4 SECURE DIGITAL (SD) CARDS

NOTE:

Ensure the G1000 System is powered off before inserting an SD card.

NOTE:

Refer to Appendix B for instructions on updating databases.

The PFD and MFD data card slots use Secure Digital (SD) cards and are located on the upper right side of the

display bezels. Each display bezel is equipped with two SD card slots. SD cards are used for aviation database
and system software updates as well as terrain database storage.

Installing an SD card:

Insert the SD card in the SD card slot (the front of the card should be ﬂush with the face of the display bezel).

To eject the card, gently press on the SD card to release the spring latch.

Figure 1-5 Display Bezel SD Card Slots

SD Card Slots
