GPS NAVIGATION
190-00692-00 Rev. B 5-132 Garmin G1000 Pilot’s Guide for Piper PA32
4) Select a departure.
5) Press the ENT Key. The RUNWAY window may be displayed.
6) Select a runway.
7) Press the ENT Key. The TRANSITION window may be displayed.
8) Select a transition.
9) Press the ENT Key. The departure is now ready to load.
10) Press the FMS Knob to remove the cursor.
Figure 5-141 Departure Information Page
Airport Information
Available Departures
Available Transitions
List of Legs
in Departure
Sequence
Available Runways
Map Showing
Selected
Departure
Act ivating a departure leg:
1) Press the FPL key.
2) Press the FMS Knob to activate the cursor.
3) Turn the large FMS Knob to highlight the desired waypoint within the departure.
4) Press the ACT LEG Softkey. A confirmation window showing the selected leg will be displayed.
5) With ‘ACTIVATE’ highlighted, press the ENT key.
Figure 5-142 Activate Leg Option
