Garmin G1000 Piper PA32 - Manual (Page 188)

GPS NAVIGATION
190-00692-00 Rev. B 5-54 Garmin G1000 Pilot’s Guide for Piper PA32
5.11 NEAREST AIRPORTS (MFD)
Figure 5-51 Nearest Airports Page
Airport Name,
Closest City,
Elevation
Length of Longest
Hard Surface Runway
(or soft surface, if no
hard surface runway
exists)
Primary
Communications
Frequency and Type
Most Precise
Approaches
Available
Airport Identifier,
Symbol, Bearing to
the Airport from
Current Position, and
Distance (up to 25
airports within 200
nm of the current
position)
Accessing information for a specific airport:
1) Select the NRST Page Group.
2) Select the first rectangular page icon.
3) With the Nearest Airports Page displayed, press the APT Softkey or press the FMS Knob to place the cursor in
the ‘NEAREST AIRPORTS’ field. The first airport in the nearest airports list is highlighted. If there are no Nearest
Airports available, “NONE WITHIN 200NM” is displayed.
4) Highlight the desired airport.
5) Press the FMS Knob to remove the flashing cursor.
OR:
1) With the Nearest Airports Page displayed, press the MENU Key.
2) Select the option ‘Select Airport Window’ and press the ENT Key. The cursor is placed in the ‘NEAREST AIRPORTS’
field.
3) Highlight the desired airport.
4) Press the FMS Knob to remove the flashing cursor.
