Using the RAID GUI
2-8
Fan module
(This icon will be
shown when the
fan is installed on
the controller.) • Controller Fan
BBM
(This icon will be
shown when the
BBM control is on.)
• State
• Remaining Capacity
• Voltage (V)
• Temperature (ºC/ºF)
• Non-critical Temperature (ºC/ºF)*
• Critical Temperature (ºC/ºF)*
UPS (This icon will
be shown when the
UPS control is on.)
UPS Status
• State
• Load Percentage
• Temperature (ºC/ºF)
• AC Input Quality/ High Voltage (V)/
Low Voltage (V)
Battery Status
• State
• Voltage (V)
• Remaining Power in percentage/
seconds
Table 2-4 Information icons
