Using the RAID GUI
2-64
2. After setting done, click Apply to make it available
• Delete a CHAP User
Select the iSNS server you want to delete and click Remove.
2.8.2.2.6 Aggregate, RM-Aggr
The Aggregation function is following 802.3ad specification, which
supports combining multiple physical iSCSI links into one logical link. That
is, increasing bandwidth, path redundancy and avoids single points of
failure.
• Create Aggregation port
1. Click Aggregate icon to open the configurations, specify the following;
2. After setting done, click Apply and restart RAID system to make it available.
• Delete Aggregation port
Click the RM-Aggr icon to open configuration window. Select the
aggregation port and click Remove.
Note
• Support Primary and Secondary iSNS server.
Assignment Method DHCP / Static (Default)
IP Address Specifies a IP address for controller A.
Network Mask Specifies a network mask address controller A.
Gateway Specifies a gateway address controller A.
IP Address Specifies a IP address for controller B.
Network Mask Specifies a network mask address controller B.
Gateway Specifies a gateway address controller B.
Jumbo Frame Enable or Disable (Default)
Aggregation Select the ISP ports bound to aggregation
port.
