76
5. Using On-Screen Menu
❷
Menu Elements
Solid triangle
Menu mode
Tab
Radio button
High Altitude symbol
ECO mode symbol
Menu windows or dialog boxes typically have the following elements:
Highlight Indicates the selected menu or item.
Solid triangle Indicates further choices are available. A highlighted triangle indicates the item is active.
Tab Indicates a group of features in a dialog box. Selecting on any tab brings its page to the front.
Radio button Use this round button to select an option in a dialog box.
Source Indicates the currently selected source.
Menu mode Indicates the current menu mode: BASIC or ADVANCED.
Off Timer remaining time Indicates the remaining countdown time when the [OFF TIMER] is preset.
Slide bar
Indicates settings or the direction of adjustment.
ECO mode symbol Indicates [ECO MODE] is set.
Key Lock symbol Indicates the [CONTROL PANEL LOCK] is enabled.
Thermometer symbol Indicates the [ECO MODE] is forcibly set to [ON] mode because the internal temperature is too
high.
High Altitude symbol Indicates the [FAN MODE] is set to [HIGH ALTITUDE] mode.
Source
Available buttons
Thermometer symbol
Key Lock symbol
Off Timer remaining time
Highlight
Slide bar
Slide bar
