44
3. Convenient Features
Handling of the Address for Operation via a Browser
Regarding the actual address that is entered for the address or entered to the URL column when operation of the projector is
via a browser, the host name can be used as it is when the host name corresponding to the IP address of the projector has been
registered to the domain name server by a network administrator, or the host name corresponding to the IP address of the pro-
jector has been set in the “HOSTS” file of the computer being used.
Example 1: When the host name of the projector has been set to “pj.ricoh.com”, access is gained to the network setting by
specifying
http://pj.ricoh.com/index.html
for the address or the entry column of the URL.
Example 2: When the IP address of the projector is “192.168.73.1”, access is gained to the network setting by specifying
http://192.168.73.1/index.html
for the address or the entry column of the URL.
PROJECTOR ADJUSTMENT
Projector adjustment screen
POWER: This controls the power of the projector.
ON ......................................Power is switched on.
OFF ....................................Power is switched off.
VOLUME: This controls the volume of the projector.
▲
........................................Increases the volume adjustment value.
▼
........................................Decreases the volume adjustment value.
AV-MUTE: This controls the mute function of the projector.
PICTURE ON.................Mutes the video.
PICTURE OFF ...............Cancels the video muting.
SOUND ON ...................Mutes the audio.
SOUND OFF .................Cancels the audio muting.
ALL ON ............................Mutes each of the video, and audio functions.
ALL OFF ..........................Cancels the muting of each of the video, and audio functions.
