232
10. Appendix
WXGA Type
Screen size
Lens model name
Replacement Lens
Type1
Replacement Lens
Type8
Replacement Lens
Type2
Standard Lens Type1 Replacement Lens
Type3
Replacement Lens
Type4
30"
0.7 - 1.0
40"
0.7
1.0 - 1.3
1.2 - 2.5
60"
1.0
1.0 - 1.3
1.5 - 2.0
1.9 - 3.8
3.7 - 6.0
5.9 - 9.1
80"
1.4
1.4 - 1.8
2.0 - 2.6
2.5 - 5.1
5.0 - 8.1
7.9 - 12.1
100"
1.7
1.7 - 2.2
2.5 - 3.3
3.2 - 6.4
6.3 - 10.1
9.9 - 15.2
120"
2.1
2.0 - 2.7
3.0 - 4.0
3.9 - 7.7
7.6 - 12.2
12.0 - 18.3
150"
2.6
2.6 - 3.4
3.8 - 5.0
4.8 - 9.6
9.5 - 15.3
15.0 - 22.9
200"
3.4 - 4.5
5.1 - 6.6
6.4 - 12.8
12.7 - 20.4
20.1 - 30.6
240"
4.1 - 5.4
6.1 - 8.0
7.7 - 15.4
15.3 - 24.5
24.1 - 36.8
300"
5.2 - 6.8
7.7 - 10.0
9.6 - 19.2
19.1 - 30.7
30.2 - 46.0
400"
6.9 - 9.0
10.2 - 13.3
12.8 - 25.7
25.5 - 40.9
40.4 - 61.4
500"
8.7 - 11.3
12.8 - 16.7
16.0 - 32.1
31.9 - 51.2
50.5 - 76.9
TIP
Calculation of the throw distance from the screen size
Replacement Lens Type1 lens throw distance (m) = H × 0.8 : 0.7 m (min.) to 2.6 m (max.)
Replacement Lens Type8 lens throw distance (m) = H × 0.8 to H × 1.0 : 1.0 m (min.) to 11.3 m (max.)
Replacement Lens Type2 lensthrow distance (m) = H × 1.2 to H × 1.5 : 0.7 m (min.) to 16.7 m (max.)
Standard Lens Type1 lens throw distance (m) = H × 1.5 to H × 3.0 : 1.2 m (min.) to 32.1 m (max.)
Replacement Lens Type3 lens throw distance (m) = H × 2.9 to H × 4.7 : 3.7 m (min.) to 51.2 m (max.)
Replacement Lens Type4 lens throw distance (m) = H × 4.6 to H × 7.1 : 5.9 m (min.) to 76.9 m (max.)
“H” (Horizontal) refers to the screen width.
* Figures differ by several % with the table above because the calculation is approximate.
Ex.: Throw distance when projecting on a 150" screen with the WXGA Type using the Standard Lens Type1:
According to the “Screen Size (for reference)” table (
→
page
), H (screen width) = 323.1 cm.
The throw distance is 323.1 cm × 1.5 to 323.1 cm × 3.0 = 484.7 cm to 969.3 cm (because of the zoom lens).
XGA Type
Screen size
Lens model name
Replacement Lens
Type1
Replacement Lens
Type8
Replacement Lens
Type2
Standard Lens Type1 Replacement Lens
Type3
Replacement Lens
Type4
30"
0.7 - 0.9
40"
0.6
0.9 - 1.2
1.2 - 2.4
60"
1.0
1.0 - 1.3
1.4 - 1.9
1.8 - 3.7
3.6 - 5.8
5.7 - 8.7
80"
1.3
1.3 - 1.7
1.9 - 2.5
2.4 - 4.9
4.8 - 7.8
7.6 - 11.6
100"
1.6
1.6 - 2.1
2.4 - 3.2
3.0 - 6.1
6.0 - 9.7
9.6 - 14.6
120"
2.0
2.0 - 2.6
2.9 - 3.8
3.7 - 7.4
7.3 - 11.7
11.5 - 17.6
150"
2.5
2.5 - 3.2
3.7 - 4.8
4.6 - 9.2
9.1 - 14.7
14.4 - 22.0
200"
3.3 - 4.3
4.9 - 6.4
6.1 - 12.3
12.2 - 19.6
19.3 - 29.4
240"
4.0 - 5.2
5.9 - 7.7
7.4 - 14.8
14.7 - 23.6
23.2 - 35.3
300"
5.0 - 6.5
7.4 - 9.6
9.2 - 18.5
18.4 - 29.5
29.1 - 44.2
400"
6.7 - 8.7
9.8 - 12.8
12.3 - 24.7
24.6 - 39.4
38.8 - 59.0
500"
8.4 - 10.9
12.3 - 16.0
15.4 - 30.8
30.7 - 49.2
48.6 - 73.8
TIP
Calculation of the throw distance from the screen size
Replacement Lens Type1 lens throw distance (m) = H × 0.8 : 0.6 m (min.) to 2.5 m (max.)
Replacement Lens Type8 lens throw distance (m) = H × 0.8 to H × 1.1 : 1.0 m (min.) to 10.9 m (max.)
Replacement Lens Type2 lens throw distance (m) = H × 1.2 to H × 1.6 : 0.7 m (min.) to 16.0 m (max.)
Standard Lens Type1 lens throw distance (m) = H × 1.5 to H × 3.0 : 1.2 m (min.) to 30.8 m (max.)
Replacement Lens Type3 lens throw distance (m) = H × 3.0 to H × 4.8 : 3.6 m (min.) to 49.2 m (max.)
Replacement Lens Type4 lens throw distance (m) = H × 4.7 to H × 7.3 : 5.7 m (min.) to 73.8 m (max.)
“H” (Horizontal) refers to the screen width.
* Figures differ by several % with the table above because the calculation is approximate.
