99
5. Using On-Screen Menu
TIP:
The horizontal position and vertical position are the amount of movement from the reference points. For example, when TOP-LEFT is adjusted, the position is displayed
with the same amount of movement even if displayed with other starting positions.
The maximum amount of movement is half the resolution of the projector.
Reference point
Adjust using the horizontal
position
Sub-display Main display
Reference point
Adjust using the vertical position
TOP-LEFT TOP-RIGHT
BOTTOM-LEFT BOTTOM-RIGHT
Reference point Reference point
BORDER
Select the display boundary of the main display and sub-display of the [PICTURE BY PICTURE] screen.
Display boundary
Main display Sub-display Main display Sub-display Main display Sub-display
TIP:
• For WUXGA type, six steps can be selected.
• For WXGA type/XGA type, three steps can be selected.
