166
6. Installation and Connections
Connecting to a Wired LAN
The projector comes standard with a Ethernet port (RJ-45) which provides a LAN connection using a LAN cable.
To use a LAN connection, you are required to set the LAN on the projector menu. Select [SETUP]
→ [NETWORK SETTINGS] →
[WIRED LAN]. ( → page 121 ).
Example of LAN connection
Example of wired LAN connection
Server
Hub
LAN cable (not supplied)
NOTE: Use a Category 5 or higher LAN cable.
