427
Scanned Image is Misaligned
If the scanned image is not aligned correctly, try these solutions:
• Change the direction of the original.
• If the original is curled, try to correct the curl before loading the original.
• Perform Image Stitching Adjustment .
• Use the optional carrier sheet.
Adjusting Scanned Image Stitching
Parent topic: Solving Scanning Problems (SureColor T5770DM/T7770DM)
Adjusting Scanned Image Stitching
If your scanned images are not aligned correctly, you can adjust the way the image is stitched together.
In the image below, the scanned image is misaligned in the center. The arrow shows the feed direction
of the original.
1. Press the home button, if necessary.
2. Select > General Settings > Scan Settings > Scan Options > Image Stitching Adjustment .
