353
Print Head Nozzle Check
You can print a nozzle check pattern to check for clogged nozzles.
Checking the Nozzles Using the Product Control Panel
Checking the Nozzles Using a Computer Utility
Parent topic: Print Head Maintenance
Checking the Nozzles Using the Product Control Panel
You can check the print head nozzles using the control panel on your product.
1. Make sure roll paper or cut sheet paper is loaded in the printer.
2. Make sure the correct paper type is selected.
3. Select > Maintenance > Print Head Nozzle Check .
4. Select Start .
The nozzle check pattern prints.
5. Check the printed pattern to see if there are gaps in the lines.
Print head is clean
Print head needs cleaning
6. Do one of the following:
• If there are no gaps, select O to exit.
• If there are gaps or the pattern is faint, select X to perform head cleaning.
7. Follow the instructions on the screen to clean the print head, check the nozzles, and repeat the
process as necessary.
Parent topic: Print Head Nozzle Check
Related references
Maintenance Menu
