Make sure the length of the loaded media is at least 22 inches (558 mm) and the width is 15 inches (388
mm) or wider. When adjusting using commercially available paper, make sure you register the custom
paper in advance.
1. Select a paper type that matches the paper in the printer.
2. Select
>
Paper Setting
> paper source >
Print Adjustments
>
Paper Feed Adjust
from the
control panel.
3. Select the paper feed adjustment that best suits your needs and intended use.
4. If you select manual adjustment, follow the on-screen instructions to make adjustments.
Parent topic:
About Auto Take-up (Dual Roll Models Only)
The auto take-up function automatically rolls up printed media as you print. You can use Roll 1 as a take-
up unit for media with the printable side in (on the right) or printable side out (on the left).
Note:
Auto take-up is not available on SureColor P6570E/T3770E.
It is best to do the following when using the auto take-up function:
• Cut the end of the roll in a V-shape to allow for easy take-up onto the core.
• Use a take-up roll core that is the same width as your media so the core does not bend or take up
media incorrectly.
Loading Media for Auto Take-up
Removing the Auto Take-up Media
Parent topic:
Loading Media for Auto Take-up
Load paper in the Roll 2 unit and set up Roll 1 for auto take-up.
