305
Setting Options Description
Select Target Poster(Photo)/ Perspective
(SureColor P-Series only)
Select desired settings
Poster/Document (SureColor
T-Series only)
GIS
CAD/Line Drawing
Off (No Color Management)
Save To Optional storage
unit
(all models except for
SureColor
T5770DM/T7770DM)
Print And Save Select settings for the optional SSD unit
Print Only
Save Only
Save to Storage
(SureColor
T5770DM/T7770DM only)
Print And Save Select settings for the SSD unit
Print Only
Save Only
HP-GL/2 Unique Settings
Adjust these settings as necessary when printing in HP-GL/2 or HP RTL mode.
Setting Options Description
Rotate 0°
90°
180°
270°
Rotate the coordinates of the drawn data
counterclockwise before printing
Origin Setup Left Edge
Center
Set the data coordinate origin
Mirror Image On Select to horizontally flip the image using
the center of the output size width as the
basis line
Off Select to print without flipping the image
