Replacing Data Cartridge Magazines
PLS200 Library Installation and Operation 49
Replacing Data Cartridge Magazines
To open the door and replace a data cartridge magazine:
1. Turn the door latch handle one quarter turn to the right, as shown in
Figure 3-2.
➤ Important Do not open the library door unless you need to remove and
replace cartridge magazines or perform a maintenance operation. It takes 2
to 5 minutes for the library to update the cartridge inventory after the door
is opened and closed.
Figure 3-2 Opening the library door
When you unlock the door:
- The library completes its current operation, moves the CHM to the home
position at the bottom of the long axis, rotates the drum assembly to the
home position, and turns off current to all motors.
- The interlock mechanism releases.
