Chapter 4 Parameters|
Revision May 2008, ME14, SW V3.04 4-61
2.2 11-bit character frame (For 8-bit character):
Start
bit
0 1 2 3 4 5 6
Stop
bit Stop
bit
8-data bits
11-bits character frame
( 8.N.2:Pr.92=3)
Start
bit
0 1 2 3 4 5 6
Even
parity Stop
bit
8-data bits
11-bits character frame
( 8.E.1:Pr.92=4)
Start
bit
0 1 2 3 4 5 6
Stop
bit
8-data bits
11-bits character frame
( 8.O.1:Pr.92=5)
Odd
parity
7
7
7
3. Communication Protocol
3.1 Communication Data Frame:
STX ADR1 ADR0 CMD1 CMD0 0 1 ...... N-1 N ETX CHK1 CHK0
02H Address CMD Data characters 03H Check Sum
3.2 ASCII mode:
STX Start character: (3AH)
ADR 1
ADR 0
CMD 1
CMD 0
Communication address:
8-bit address consists of 2 ASCII codes
DATA (n-1)
……
DATA 0
Contents of data:
n x 8-bit data consist of 2n ASCII codes.
n ≦25 maximum of 50 ASCII codes
LRC CHK 1
LRC CHK 0
LRC check sum:
8-bit check sum consists of 2 ASCII codes
END 1
END 0
END characters:
END 1 = CR (0DH), END 0 = LF (0AH)
