B.8.1 dimensions – Delta Electronics VFD-M User Manual
Page 162
Appendix B Accessories|
Revision May 2008, ME14, SW V3.04
B-17
B.8.1 Dimensions
EMI Filter (RF015M21AA / RF022M43AA)
70
(2.76)
226
(8.9)
100
(3.94)
212
(8.35)
212
(8.35)
28
(1.1)
50
(1.97)
26
(1.02)
15
(0.59)
4.5
(0.18)
EMI Filter (RF022M21BA / RF075M43BA)
30
(1.18)
60
(2.36)
282
(11.1)
15
(0.59)
30
(1.18)
80
(3.15)
125
(4.82)
282
(11.1)
295
(11.61)
5.5
(0.22)
