B.3 fuse specification chart – Delta Electronics VFD-M User Manual
Page 151
Appendix B Accessories|
B-6
Revision May 2008, ME14, SW V3.04
B.3 Fuse Specification Chart
Smaller fuses than those shown in the table are permitted.
Line Fuse
Model
Input Current (A)
Output Current (A)
I (A)
Bussmann P/N
VFD002M11A 6
1.6 15
JJN-15
VFD004M11A 9
2.5 20
JJN-20
VFD007M11A 16
4.2
30 JJN-30
VFD004M21A 6.3
2.5
15 JJN-15
VFD004M21B 6.3
2.5
15 JJN-15
VFD007M21A 11.5
5.0
20 JJN-20
VFD007M21B 11.5
5.0
20 JJN-20
VFD015M21A 15.7
7.0
30 JJN-30
VFD015M21B 15.7
7.0
30 JJN-30
VFD022M21A 27
10
50 JJN-50
VFD004M23A 2.9
2.5
5 JJN-6
VFD007M23A 7.6
5.0
15 JJN-15
VFD015M23A 8.8
7.0
20 JJN-20
VFD022M23B 12.5
10.0
30 JJN-30
VFD037M23A 19.6
17
40 JJN-40
VFD055M23A 28
25
50 JJN-50
VFD007M43B 4.2
3.0
5 JJS-6
VFD015M43B 5.7
4.0
10 JJS-10
VFD022M43B 6.0
5.0
15 JJS-15
VFD037M43A 8.5
8.2
20 JJS-20
VFD055M43A 14
13
30 JJS-30
VFD075M43A 23
18
50 JJS-50
VFD007M53A 2.4
1.7
5 JJS-6
VFD015M53A 4.2
3.0
10 JJS-10
VFD022M53A 5.9
4.2
15 JJS-15
VFD037M53A 7.0
6.6
15 JJS-15
VFD055M53A 10.5
9.9
20 JJS-20
VFD075M53A 12.9
12.2
30 JJS-50
