Chapter 4 Parameters|
Revision May 2008, ME14, SW V3.04 4-69
Content Address Functions
2100H
Error code:
00: No errors occurred
01: Over-current (oc)
03: Overheat (oH)
04: Drive overload (oL)
05: Motor overload1 (oL1)
06: External fault (EF)
07: CPU failure (cF1)
08: CPU or analog circuit failure (cF3)
09: Hardware protection failure (HPF)
10: Current exceeds 2 times rated current during accel (ocA)
11: Current exceeds 2 times rated current during decel (ocd)
12: Current exceeds 2 times rated current during steady state
operation (ocn)
13: Ground Fault (GF)
14: Low voltage (Lv)
15: Reserved
16: CPU failure 1 (cF2)
17: Base block
18: Overload (oL2)
19: Auto accel/decel failure (cFA)
20: Software protection enable (codE)
Status of AC Drive
00: RUN LED light off, STOP LED light up
01: RUN LED blink, STOP LED light up
10: RUN LED light up, STOP LED blink
Bit 0-1
11: RUN LED light up, STOP LED light off
Bit 2 01: Jog active
00: REV LED light off, FWD LED light up
01: REV LED blink, FWD LED light up
10: REV LED light up, FWD LED blink
2101H
Bit 3-4
11: REV LED light up, FWD LED light off
Bit 5-7 Reserved
Bit 8 1: Main freq. Controlled by communication
Bit 9 1: Main freq. Controlled by external terminal
Bit 10
1: Operation command controlled by
communication
Bit 11 1: Parameters have been locked
Bit 12 0: Stop 1: Run
Bit 13 1: Jog command
Bit 14-15 Reserved
2102H Frequency command F (XXX.XX)
2103H Output Frequency H (XXX.XX)
2104H Output Current A (XXX.X)
Status monitor
Read only
2105H DC-BUS Voltage U (XXX.X)
