Chapter 4 Parameters|
4-58 Revision May 2008, ME14, SW V3.04
Pr.80 Identity Code of the AC Motor Drive
Settings Read Only Factory Setting: ##
This parameter displays the identity code of the AC motor drive. The capacity, rated current,
rated voltage and the max. carrier frequency relate to the identity code. Users can use the
following table to check how the rated current, rated voltage and max. carrier frequency of the
AC motor drive correspond to the identity code.
115V series 230V series
kW 0.2 0.4 0.75 0.4 0.75 1.5 2.2 3.7 5.5
HP 0.25 0.5 1.0 0.5 1 2 3 5 7.5
Model Number (Pr.80) 20 22 24 00 02 04 06 08 10
Rated Output Current (A) 1.6 2.5 4.2 2.5 5.0 7.0 10 17 25
Max. Carrier Frequency (kHz) 15kHz
460V series 575V series
kW 0.75 1.5 2.2 3.7 5.5 7.5 0.75 1.5 2.2 3.7 5.5 7.5
HP 1 2 3 5 7.5 10 1 2 3 5 7.5 10
Model Number (Pr.80) 03 05 07 09 11 13 50 51 52 53 54 55
Rated Output Current (A) 3.0 4.0 5.0 8.2 13 18 1.7 3.0 4.2 6.6 9.9 12.2
Max. Carrier Frequency (kHz) 15kHz 10kHz
Pr.81 Time Duration of 1st Step Speed (correspond to Pr.17) Unit: 1 sec
Pr.82 Time Duration of 2nd Step Speed (correspond to Pr.18) Unit: 1 sec
Pr.83 Time Duration of 3rd Step Speed (correspond to Pr.19) Unit: 1 sec
Pr.84 Time Duration of 4th Step Speed (correspond to Pr.20) Unit: 1 sec
Pr.85 Time Duration of 5th Step Speed (correspond to Pr.21) Unit: 1 sec
Pr.86 Time Duration of 6th Step Speed (correspond to Pr.22) Unit: 1 sec
Pr.87 Time Duration of 7th Step Speed (correspond to Pr.23) Unit: 1 sec
Settings 00 to 9999 second Factory Setting: 00
Pr.81 to Pr.87 input the duration of each Multi-step speed operation defined by Pr.17 to Pr.23.
Note: If any duration is set to “0” (sec), the corresponding step operation will be skipped. This is
commonly used to reduce the number of program steps.
Pr.88 Communication Address
Settings 01 to 254 Factory Setting: 01
