B.9.2 din rail-dr02 adapter – Delta Electronics VFD-M User Manual
Page 165
Appendix B Accessories|
B-20
Revision May 2008, ME14, SW V3.04
B.9.2 Din Rail-DR02 Adapter
Units: mm (inch)
Models
VFD002M11A, VFD004M11A/21B, VFD007M11A/21B/43B/53A, VFD015M21B/43B/53A,
VFD022M23B/43B/53A
To mount the drive on a Din Rail adapter, place the drive and mounting plate on the rail and
push the lever toward the rail.
