Appendix A Specifications
There are 115V, 230V, 460V and 575V models in the VFD-M series. For 115V models, it is 1-phase
models. For 0.5 to 3HP of the 230V models, there are 1-phase/3-phase models. Refer to following
specifications for details.
Voltage Class 115V Class
Model Number VFD-XXXM 002 004 007
Max. Applicable Motor Output (kW) 0.2 0.4 0.75
Max. Applicable Motor Output (hp) 0.25 0.5 1.0
Rated Output Capacity (kVA) 0.6 1.0 1.6
Rated Output Current (A) 1.6 2.5 4.2
Maximum Output Voltage (V) 3-Phase proportion to twice the input voltage
Output Frequency (Hz) 0.1~400 Hz
Outpu
t Ra
ting
Carrier Frequency (kHz) 1-15
Single phase
Rated Input Current (A)
6 9 16
Rated Voltage, Frequency Single phase, 100-120 VAC, 50/60Hz
Voltage Tolerance ± 10% (90-132VAC)
Inpu
t Ra
ting
Frequency Tolerance
± 5% (47~63Hz)
Cooling Method Fan Cooled
Weight (kg) 1.5 1.5 1.5
Voltage Class 230V Class
Model Number VFD-XXXM 004 007 015 022 037 055
Max. Applicable Motor Output (kW) 0.4 0.75 1.5 2.2 3.7 5.5
Max. Applicable Motor Output (hp) 0.5 1.0 2.0 3.0 5.0 7.5
Rated Output Capacity (kVA) 1.0 1.9 2.7 3.8 6.5 9.5
Rated Output Current (A) 2.5 5.0 7.0 10 17 25
Maximum Output Voltage (V) 3-Phase proportional to input voltage
Output Frequency (Hz) 0.1~400 Hz
Outpu
t Ra
ting
Carrier Frequency (kHz) 1-15
Single/3-phase 3-phase
Rated Input Current (A)
6.3/2.9 11.5/7.6 15.7/8.8 27/12.5 19.6 28
Input Current for 1-phase
Models when Using 3-phase
Power
3.2 6.3 9.0 12.5 -- --
Rated Voltage, Frequency
Single/3-phase
200-240 VAC, 50/60Hz
3-phase
200-240VAC,
50/60Hz
Voltage Tolerance
± 10% (180~264 VAC)
Inpu
t Ra
ting
Frequency Tolerance
± 5% (47~63 Hz)
Cooling Method Fan Cooled
Weight (kg) 2.2/1.5 2.2/1.5 2.2/1.5 3.2/2.2 3.2 3.2
