Chapter 4 Parameters|

Revision May 2008, ME14, SW V3.04

4-79

Pr. 122

PID Frequency Output Command limit

Settings 00 to 110 %

Factory Setting: 100

This parameter sets a limit of the PID Command frequency. If this parameter is set to 20%,

then the maximum output frequency for the PID operation will be (20% x Pr.03).

Pr. 123

Feedback Signal Detection Time

Unit: 0.1sec

Factory Setting: 60.0

Settings 0.1 to 3600 sec

0.0

disable

This parameter defines the detection time for the loss of a feedback analog signal. The drive

will follow the operating procedure programmed in Pr.124 if the feedback signal is lost for more

than the time set in Pr.123.

Pr. 124

Feedback Signal Fault Treatment

Factory Setting: 00

Settings 00 Warning and RAMP to stop

01 Warning and keep operating

This parameter selects the operation of the drive upon a loss of the PID feedback signal.

Pr. 125

Source of PID Set point

Settings 0.00 to 400.0Hz

Factory Setting: 0.00

This parameter is used in conjunction with Pr.115 (04) to input a set point in Hz.

Pr. 126

PID Offset Level

Settings 1.0 to 50.0 %

Factory Setting: 10.0

This parameter is used to set the offset between set point and feedback.

Pr. 127

Detection Time of PID Offset

Settings 0.1 to 300.0 sec

Factory Setting: 5.0

This parameter is used to set the detection time of PID offset.

Pr. 128

Minimum Reference Value

Unit: 0.1V

Settings 0.0 to 10.0 V

Factory Setting: 0.0

This parameter is used to set the AVI input voltage that corresponds to minimum frequency.
