Appendix A Specifications|

Revision May 2008, ME14, SW V3.04

A-3

General Specifications

Keypad

Setting by

Frequency
Setting

External

Signal

Potentiometer-5K

Ω/0.5W, 0 to +10VDC, 4 to 20mA RS-485

interface; Multi-Function Inputs 0 to 5 (7 steps, Jog, up/down)

Keypad

Set by RUN, STOP

Operation
Setting
Signal

External

Signal

M0 to M5 can be combined to offer various modes of operation,
RS-485 serial interface (MODBUS).

Multi-Function Input Signal

Multi-step selection 0 to 7, Jog, accel/decel inhibit, first to forth
accel/decel switches, counter, PLC operation, external Base
Block (NC, NO), auxiliary motor control is invalid, selections,
driver reset, UP/DOWN key settings, sink/source selection

Multi-Function Output
Indication

AC drive operating, frequency attained, non-zero, base block,
fault indication, local/remote indication, PLC operation indication,
auxiliary motor output, driver is ready, overheat alarm, emergency
stop

Operati

ng Char

acte

ristics

Analog Output Signal

Analog frequency/current signal output.

Alarm Output Contact

1 Form C contact or open collector output

Operation Functions

AVR, S-Curve, over-voltage, over-current stall prevention, fault
records, adjustable carrier frequency, DC braking, momentary
power loss restart, auto tuning, frequency limits, parameter
Lock/Reset, vector control, counter, PID Control, PLC, MODBUS
communication, reverse Inhibition, abnormal reset, abnormal re-
start, digital frequency output, sleep/revival function, 1st/2nd
frequency source selections

Protection Functions

Self-testing, over voltage, over current, under voltage, overload,
overheating, external fault, electronic thermal, ground fault.

Display Keypads

6-key, 4-digit, 7-segment LED, 4 status LEDs, master frequency,
output frequency, output current, custom units, parameter values
for setup, review and faults, RUN, STOP, RESET, FWD/REV

Built-in Brake Chopper

Built-in for all models

Protection Level

IP20

Pollution Degree

2

Installation Location

Altitude 1,000 m or lower, keep from corrosive gasses, liquid and
dust

Ambient Temperature

-10

o

C to 40

o

C (-10

o

C to 50

o

C without blind plate)

Non-Condensing and not frozen

Storage/ Transportation
Temperature

-20

o

C to 60

o

C

Ambient Humidity

Below 90% RH (non-condensing)

Enviromen

tal

Condi

tion

s

Vibration 9.80665m/s

2

(1G) less than 20Hz, 5.88m/s

2

(0.6G) at 20 to 50Hz

Approvals

Note: Do not attempt to connect a single-phase power source to a three-phase models drive.

However it is acceptable to connect two wires of a three-phase power source to a single-
phase drive.
