Chapter 4 Parameters|
Revision May 2008, ME14, SW V3.04 4-3
Parameter Explanation Settings
Factory
Setting
Customer
Pr.08 Minimum Output Freq 0.10 to 20.00Hz 1.50
115V/230V: 0.1 to 255.0V 10.0
460V: 0.1 to 510.0V 20.0 Pr.09
Minimum Output
Voltage
575V: 0.1 to 637.0V 26.1
Pr.10 Acceleration Time 1 0.1 to 600.0 sec or 0.01 to 600.0 sec 10.0
Pr.11 Deceleration Time 1 0.1 to 600.0 sec or 0.01 to 600.0 sec 10.0
Pr.12 Acceleration Time 2 0.1 to 600.0 sec or 0.01 to 600.0 sec 10.0
Pr.13 Deceleration Time 2 0.1 to 600.0 sec or 0.01 to 600.0 sec 10.0
Pr.14 Accel S-curve 00 to 07 00
Pr.15 Jog Accel/Decel Time 0.1 to 600.0 sec or 0.01 to 600.0 sec 1.0
Pr.16 Jog Frequency 0.00 to 400.0 Hz 6.00
Pr.17 1st Step Speed Freq. 0.00 to 400.0Hz 0.00
Pr.18 2nd Step Speed Freq. 0.00 to 400.0Hz 0.00
Pr.19 3rd Step Speed Freq. 0.00 to 400.0Hz 0.00
Pr.20 4th Step Speed Freq. 0.00 to 400.0Hz 0.00
Pr.21 5th Step Speed Freq. 0.00 to 400.0Hz 0.00
Pr.22 6th Step Speed Freq. 0.00 to 400.0Hz 0.00
Pr.23 7th Step Speed Freq. 0.00 to 400.0Hz 0.00
Pr.24
Reverse Operation
Inhibition
00: Enable REV operation
01: Disable REV operation
00
00: Disable
115V/230V: 330 to 450 Vdc 390
460V: 660 to 900 Vdc 780
Pr.25
Over-Voltage Stall
Prevention
575V: 825 to 1025 Vdc 975
Pr.26
Over-current Stall
Prevention during
Acceleration
00: Disable
20% to 200%
150
Pr.27
Over-current Stall
Prevention during
Operation
00: Disable
20% to 200%
150
Pr.28
DC Braking Current
Level
00 to 100 % 00
Pr.29
DC Braking during
Start-up
0.0 to 5.0 sec 0.0
