Form I-RDH/REH/RHH/RXH (12-14), P/N 215210 R14, Page 15

5.3 Rigging and

Lifting

NOTE: Apply gasketing to

the roof curb prior to lifting

the unit and setting it on the

curb.

1. Position curb cross rails and curb side rails as illustrated in FIGURE 8, page 12.

Using the hardware provided, join the corners as illustrated in the corner detail

(

FIGURE 9).

2. Check the assembly for squareness. Adjust the roof curb so that the diagonal

measurements are equal within a tolerance of ±1/8” (3mm).

3. Level the roof curb. To ensure proper condensate drainage and a weathertight

seal between the system curb cap and the roof curb, the roof curb must be leveled

in both directions with no twist end to end. Shim level as required and secure curb

to roof deck before proceeding with flashing.

4. Install field-supplied flashing.

5. Before placing the unit on the curb, apply furnished 1/4” x 1-1/4” foam sealant tape

to top surface of curb, making good butt joint at corners. The unit must be sealed

to the curb to prevent water leakage into the curb area due to blown rain and

capillary action.

6.1.1 Gas Supply and

Connections

6.0 Mechanical

6.1 Gas Piping and Pressures - Models RDH and RHH

NOTE: Gas conversion kits

are available for changing

units with 1-stage and

2-stage gas controls (Option

AG1, AG2, AG3, AG15, and

AG16) from natural gas

to propane or propane to

natural gas.
Gas conversion kits do

not apply to a heater with

a 2-speed venter control

system (Option AG8,

AG9, AG9H, AG40, AG58,

AG60, AG61, AG62, DG1,

DG2, DG5, DG6, D12B,

and D12C) or with 8:1

modulation (Options AG58

or D12G).
Contact your distributor,

representative, or the

factory for information.

WARNING: This appliance is equipped for a maximum gas supply pressure of

1/2 psi, 3.5 kPa, or 14 inches water column.

NOTE: Supply pressures higher

than 1/2 psi require installation of an additional service regulator external to

the unit.

Pressure Testing Supply Piping:
Test Pressure Above 1/2 PSI
: Disconnect the heater and manual valve from the gas

supply which is to be pressure tested. Cap or plug the supply line.
Test Pressure Below 1/2 PSI: Before testing, close the manual valve on the heater.
All piping must be in accordance with requirements outlined in the National Fuel Gas

Code NFPA54/ANSI Z223.1 (latest edition) or CSA B149.1 (latest edition) Natural Gas

and Propane Installation Code. Gas supply piping installation should conform with

good practice and with local codes.

These units for use with natural gas are orificed for gas having a heating value of 1000

(±50) BTU per cubic ft. If the gas at the installation does not meet this specification,

consult the factory for proper orifice.

Pipe joint compounds (pipe dope) shall be resistant to the action of liquefied petroleum

gas or any other chemical constituents of the gas being supplied.

Install a ground joint union and manual shutoff valve upstream of the unit control sys-

tem. The 1/8” plugged tapping in the shutoff valve provides connection for supply line

pressure test gauge. The National Fuel Gas Code requires the installation of a trap

with a minimum 3” (76mm) drip leg. Local codes may require a longer drip leg, typically

6” (152mm). See

FIGURE 10.

WARNING

All components of a gas supply system must be leak tested prior

to placing the equipment in service. NEVER TEST FOR LEAKS

WITH AN OPEN FLAME. See Hazard Levels, page 2.

DANGER

To prevent injury, death, or equipment damage caused by inadequate or improper

rigging, test lift the unit before attempting to place it on a roof. See Hazard Intensity

Levels, page 2.

Lifting holes in the base are provided for rigging. If the circumstances require a rigging

height that is less than 12 feet (3.7M), spreader bars are required. Lift with vertical

force only.
Test lift the unit to be sure that it is secure. Lift the unit slowly, following safe lifting

procedures. Failure to lift by the manufacturer’s instructions could cause damage to

the equipment and/or personal injury or death. The equipment manufacturer is not

responsible for unsafe rigging or lifting procedures.
