10 Parameter Description
Parameter 0x22: Actual speed value averaging
Description: The registered actual speed is filtered with a digital filter for the period defined here.
Parameter 0x23: Resolution of the actual outputs
Description: The resolution of the actual outputs.
Tolerance range of the actual outputs
He
xwert
[Impulse /
revolution]
0 1000 2000 3000 4000 5000 6000
0
5
10
15
20
25
30
35
40
45
50
55
60
Difference up to 5 %
Difference up to 15 %
Difference up to 10 %
Revolution [rpm]
Parameter 0x24: Speed signal threshold
Description: The speed signal threshold (amount) parameter defined from which speed a speed signal is set at an output.
