80
8 Inputs and Outputs
P04: Use of the output OUT 2
Description: The parameter defines which status output is output at output OUT 2.
Default value: 1
Scaling:
0: no function
1: Increment_1
2: Speed signal
3: Current signal
4: Ready signal
5: Positioning window reached
6: Temperature signal
7: RS485 controlled
Dependencies: with codes 2 – 6 the corresponding threshold values must contain valid values.
P05: Use of the output OUT 3
Description: The parameter defines which status output is output at output OUT 3.
Default value: 1
Scaling:
0: no function
1: Increment_2
2: Speed signal
3: Current signal
4: Ready signal
5: Positioning window reached
6: Temperature signal
7: RS485 controlled
Dependencies: with codes 2 – 6 the corresponding threshold values must contain valid values.
U logic (common GND)
