10 Parameter Description
Parameter 0x11: FE_DREHZAHL_Y3
Description: Target speed value for interpolation point X3.
Parameter 0x12: FE_DREHZAHL_Y4
Description: Target speed value above the interpolation point X3.
Parameter 0x13: DREHZAHL_X1_HYSTERESE
Description: Interpolation point hysteresis value for X1. Value is understood as being the width of the hysteresis on the X axis and is used half under and
half above the corresponding interpolation point.
E.g.:
FE_DREHZAHL_X1 = 100,
DREHZAHL_X1_HYSTERESE = 20
If the X axis value moves upwards, from value 110 (= 100 + (20/2)) the characteristic moves to value Y1. If the X axis value moves downwards, from X axis
value 90 (= 100 – (20/2)) the characteristic jumps to Y0.
Parameter 0x14: DREHZAHL_X2_HYSTERESE
Description: Interpolation point hysteresis value for X2. Value is understood as being the width of the hysteresis on the X axis and is used half under and
half above the corresponding interpolation point.
E.g.:
FE_DREHZAHL_X2 = 100,
DREHZAHL_X2_HYSTERESE = 20
If the X axis value moves upwards, from value 110 (= 100 + (20/2)) the characteristic moves to value Y2. If the X axis value moves downwards, from X axis
value 90 (= 100 – (20/2)) the characteristic jumps to Y1.
Parameter 0x15: DREHZAHL_X3_HYSTERESE
Description: Interpolation point hysteresis value for X3. Value is understood as being the width of the hysteresis on the X axis and is used half under and
half above the corresponding interpolation point.
E.g.:
FE_DREHZAHL_X3 = 100,
DREHZAHL_X3_HYSTERESE = 20
If the X axis value moves upwards, from value 110 (= 100 + (20/2)) the characteristic moves to value Y3. If the X axis value moves downwards, from X axis
value 90 (= 100 – (20/2)) the characteristic jumps to Y2.
Parameter 0x16: FEHLER_DREHZAHL
Description: Speed setpoint in case of setpoint detection errors
