79
8 Inputs and Outputs
8.1.3 Analog IN A1
5: Analog (IN A1) (analog input (target speed > default))
input
Analog IN A1
Analog input (target speed > default)
0…10V (differential)
Analog GND GND for analog IN 1 (differential)
8.2 Output circuit
8.2.1 Output OUT 1 / Output OUT 2 / Output OUT 3
P03: Use of the output OUT 1
Description: The parameter defines which status output is output at output OUT 1.
Default value: 4 (= drive ready)
Scaling:
0: no function
1: no function (reserved)
2: Speed signal
3: Current signal
4: Ready signal
5: Positioning window reached
6: Temperature signal
7: RS485 controlled
Dependencies: with codes 2 – 6 the corresponding threshold values must contain valid values.
