ebm-papst ECI-63.XX-K4 - Manual (Page 67)

67
7 Parameterisation of the Operating Modes
7.31 Operating mode 77: Speed setpoint PWM; dynamic current limit via a2
NOTe
In order for the parameter to function, KP_H must be > 0.
Function IN 1: Input for PWM signal.
Function IN 2: Analog A2 dynamic current limitation.
Speed Current limit
IN A IN B IN 1 IN 2 Direction Value Type Value Function Comment
0 0 x x - 0 - - Free-wheeling No braking, no current feed
1 0 PWM A2 pos PWM D A2 N control
1 0 PWM A2 pos PWM D A2 N control
1 0 PWM A2 pos PWM D A2 N control
1 0 PWM A2 pos PWM D A2 N control
0 1 PWM A2 neg PWM D A2 N control
0 1 PWM A2 neg PWM D A2 N control
0 1 PWM A2 neg PWM D A2 N control
0 1 PWM A2 neg PWM D A2 N control
1 1 PWM A2 - 0 D A2 Stop Braking and stopping
1 1 PWM A2 - 0 D A2 Stop Braking and stopping
1 1 PWM A2 - 0 D A2 Stop Braking and stopping
1 1 PWM A2 - 0 D A2 Stop Braking and stopping
Stop control = If KP_H > 0; brake and stop in the current position on changeover to IN A = IN B = 1 + Coasting rh, lh.
If KP_H = 0; brake and stop on changeover to IN A = IN B = 1, run speed to 0.
S = Static
P = Parameter
F = Freeze
D = Dynamic
x = Arbitrary value
